LoRa IoT solar powered calcium ion concentration sensor

Product Introduction:

The LoRaWAN solar calcium ion sensor designed specifically for outdoor water quality monitoring integrates self-sustaining power supply, remote low-power communication, and high-precision calcium ion detection. Long term online automatic analysis of calcium ion concentration in industrial wastewater, surface water, seawater, and aquaculture scenarios can be achieved without the need for external power and signal lines, truly solving practical problems such as difficulty in obtaining electricity, expensive wiring, and troublesome maintenance outdoors.

• Stable and reliable solar power supply system: Equipped with 0.88W monocrystalline silicon solar panels and 3400mAh lithium-ion batteries, the whole machine has microampere power consumption and a battery life of ≥ 3 years under normal use conditions. Attention: Ion sensors have high power consumption, and it is not recommended to set a too short reporting period (default 30 minutes).
•  Accurate measurement of calcium ions and temperature: The default measurement range is 0-1000mg/L (switchable 0-1000mg/L), with a resolution of 0.1mg/L and an accuracy of ± 10% or ± 1mg/L of the reading; Built in Pt1000 automatic temperature compensation, while monitoring water temperature (accuracy ± 0.5 ℃), effectively eliminating environmental temperature interference.
• Flexible LoRaWAN wireless transmission: supports multiple frequency bands such as CN470/EU868/US915, OTAA Class A mode (default), open transmission distance of several kilometers; Data is directly connected to the gateway/cloud, supporting remote viewing and downstream configuration (such as modifying reporting cycles, calibrating electrodes, etc.).
• Durable and adaptable to complex water bodies: electrode wire length defaults to 5 meters (customizable), working temperature range of 0-40 ℃, pH range of 4-10; The electrode has a service life of 1-2 years and should be tilted at least 15 ° during installation (not inverted or horizontal). The calibration has been completed at the factory, and daily maintenance only requires regular cleaning of the electrodes. When not in use for a long time, they should be stored dry.

Solar calcium ion Sensor Specification:

Packaging:

Single gross weight: 1.200 KG

Single package size: 37x26x5 cm

Product Display:

Quality assurance:

1.Each production process is inspected by dedicated personnel, and every step is strictly controlled to ensure stable and reliable product quality.
2.Professional engineers coordinate the entire process of quality inspection and control, achieving closed-loop management from the source to the finished product.
3.The product has passed multiple authoritative certifications such as CE, ROHS, and metrology, and meets strict standards both domestically and internationally.

Application:

• Aquaculture: Real time monitoring of calcium ion concentration in water bodies to assist in the smooth molting and growth of crustaceans such as shrimp and crabs.
• Facility agriculture: Monitor nutrient solution and soil calcium content, scientifically regulate fertilization, and improve fruit and vegetable quality.
• Water environment monitoring: applied to rivers, lakes, and drinking water sources, long-term online monitoring of water quality hardness.
• Industrial water treatment: Monitor the calcium concentration of circulating water and boiler water to avoid scaling and loss of pipelines and equipment.

Customer on-site examples:

FAQ:

1.Are you manufacture?

A:Yes,we are Tranmitter manufacturer and exporter in China with more than 10 years of CE,ROHS,FCC,ISO and 11 patents experience.

2.Do you offer OEM services?

A:Yes,we can provide you with OEM services and design housings and logos.

3.DO you offer free samples?

A:Sorry,we don't offer free samples.After ordering in bulk,we will deduct the sample fee from the second order.

Why choose us:

• Strong R & D: 30+ Senior experts and highly educated personnel formed a R & D team, heavy investment, master a number of core technologies and patents.
• Professional and effective solutions: for smart environmental protection, agriculture and other fields, to provide customized compound networking solutions.
• Full range of products: covering the whole industry chain products from data collection to platform services to meet diverse needs.
• Excellent quality: we have perfect quality control system, strictly quality control each production link, low defective rate.
• Good service: 7×24 hours fast response, Professional pre-sale, sale, after-sales team support.
