| Brand Name: | ZONEWU |
| Model Number: | LW308D-H2 |
| MOQ: | 1 |
| Price: | Contact Us |
| Payment Terms: | T/T |
| Supply Ability: | 500 |
| Power Supply | 5~28VDC |
| Weight | 120g |
| Usage Environment | Temperature: -20℃～50℃ |
|
Humidity: 15%~ 90% RH without condensation NOTE:It is not recommended to stay in a high humidity environment for more than half a month |
|
| Measuring Principle | Electrochemical Principle |
| Measuring Range | H2: 0～1000 ppm |
| Resolution and Accuracy | H2: 1 ppm |
| Temp.and Humi. Sensor | Temp Range:-40~+80 ℃ |
| Accuracy:±0.3 ℃ | |
| Humi Range:0~99.9 %RH | |
| Accuracy:±2 %RH | |
| Sensor Lifespan | < 2 years |
| Frequency |
CN470/IN865/EU868/RU864/US915/AU915/KR920/AS923-1&2&3&4 |
| Mode | OTAA Class A/C(Default: Class C) |
| Data Collection Cycle | 10s(Default) |
| Reporting cycle |
5 min(Default reporting cycle) Report after preheating for 3 minutes when powered on |
| Communication Protocol | LoRaWAN,LoRa TDMA Networking |
|
Equipment information (Reference) |
AppEUI:0000000000000001 DevEUI:aaaa202404150001 AppKey:00001111222233334444555566667777 MAC Version:LoRaWAN 1.0.3 |
| Warranty Period | 1 year |
Single gross weight: 0.600 KG
Single package size: 23X20X5 cm
The High precision H2 gas sensor also widely used for gas monitoring of Chemical production, Ward monitoring, Vegetable greenhouse, Livestock and poultry farms, Tunnel monitoring, Cold chain logistics vehicle, Cold storage monitoring, Biosafety laboratory.
Certifications:
We are best gas sensor manufacturer and exporter in China with more than 10 years. Our H2 gas sensor products are certified with of CE, ROHS.
