| Brand Name: | ZONEWU |
| Model Number: | LW500B-T&H |
| MOQ: | 1 |
| Price: | Contact Us |
| Payment Terms: | T/T |
| Supply Ability: | 500 |
LoRaWAN Soil Temperature and Humidity Sensor
LoRa Soil Temperature and Humidity Sensor:
An all-in-one wireless IoT sensor integrating collection, monitoring and transmission functions. Simply insert it into the soil to directly measure moisture and temperature with accurate readings and fast response. It supports the standard LoRaWAN protocol for remote wireless communication, allowing users to grasp real-time soil data conveniently.
Technical Features of Soil Temperature and Humidity Sensor:
1.Fast ResponseThe sensor has a rapid response speed, capable of capturing real-time changes in soil temperature and humidity to ensure data timeliness and accuracy.
2.High-Precision MeasurementIt delivers high-precision detection performance, accurately reflecting the variations of soil temperature and moisture.
3.Compact & LightweightCompact and lightweight design for easy carrying and installation, adaptable to various complex working environments.
4.Excellent InterchangeabilityStandardized sensor design with strong interchangeability, facilitating user replacement and maintenance.
5.Superior Sealing PerformanceAdopting high-quality sealing materials, it can be directly buried in soil for use without corrosion damage.
6.Wide Application RangeSuitable for multiple soil types and various scenarios, such as water-saving agricultural irrigation, greenhouses, flower & vegetable planting, grassland and pasture, etc.
7.Efficient Data TransmissionReliable sensor performance with high-efficiency data transmission, ensuring users obtain real-time soil temperature and humidity data stably.
LoRaWAN Soil Temperature and Humidity Sensor Specification:
| Power Supply | ER26500 Li-SOCl2 8500 mAh battery,3.6V |
| LW500B Weight | 200g |
| Operating Temperature | -40℃~+60℃ |
| Soil Moisture Parameters | Range:0-100% |
| Resolution: 0.1% | |
|
Accuracy: 0-50% ± 2%, @ (brown soil, 30%, 25 ℃) 50-100% ± 3%, @ (brown soil, 60%, 25 ℃) |
|
| Soil Temperature Parameters | Range:-40~+80℃ |
| Resolution: 0.1℃ | |
| Accuracy:±0.5℃(25℃) | |
| Probe Material | Anti corrosion special electrode |
| Transmitter Line length | Default 2m (other lengths can be customized) |
| Frequency |
CN470/IN865/EU868/RU864/US915/AU915/ KR920/AS923-1&2&3&4 |
| Mode | OTAA Class A |
| Reporting cycle | 60min(Default ) |
| Battery Life |
≤3 years (Depending on the reporting cycle)
Note: Due to the high power consumption of Soil Sensor, it is not recommended touse short cycle data reports. |
| Communication Protocol | LoRaWAN |
|
Equipment information (Reference) |
AppEUI:0000000000000001 DevEUI:aaaa202404150001 AppKey:00001111222233334444555566667777 MAC Version:LoRaWAN 1.0.3 |
Product Applications:
Single gross weight: 0.800 KG
Single package size: 23X20X5 cm
Product Applications:
1.High precision: accurately measure the slightest changes in soil Temperature and Humidity, with a wide measurement range.
2.It meets the requirements of long-term agricultural monitoring and reduces operational and maintenance costs associated with frequent power replacement.
3.Features battery-powered design, compatible with outdoor deployment scenarios without external power sources.
4.Low - power wireless transmission: use LoRa technology for long - range, low - power data transmission, reducing energy consumption.
5.Strong environmental adaptability: withstand harsh outdoor conditions such as rain, dust, and extreme temperatures.
6.Easy installation and deployment: quick setup with an aviation connector and flexible placement in various soil monitoring scenarios.
Product Description:
Soil Sensor: Affordable & Fast Measurement
This is a Soil Integrated Sensor, and its key advantage is "low measurement cost". Compared with traditional laboratory measurements, it has these features:
1.Low threshold
2.Fast measurement
3.Few steps
4.No reagents required
5.Unlimited detection times
6.From the sensor label, you can also see its specifications:
Application:
The sensor is mainly oriented to smart agriculture and ecological monitoring scenarios, with strong adaptability to different scales and types of application needs:
1. Large-Scale Field Crop Planting
2. Greenhouse Horticulture & Protected Agriculture
3. Orchard & Fruit Tree Planting
4. Small-Scale Planting & Family Farms
5. Agricultural Scientific Research & Experiment
6. Ecological Restoration & Environmental Monitoring
Production Process:
Why choose us:
1. Strong R & D: 30+ Senior experts and highly educated personnel formed a R & D team, heavy investment, master a number of core technologies and patents.
2. Professional and effective solutions: for smart environmental protection, agriculture and other fields, to provide customized compound networking solutions.
3. Full range of products: covering the whole industry chain products from data collection to platform services to meet diverse needs.
4. Excellent quality: we have perfect quality control system, strictly quality control each production link, low defective rate.
5. Good service: 7×24 hours fast response, Professional pre-sale, sale, after-sales team support.
